Kia K3 II facelift (2021-2024) ext tail fl dedicate drl lh Wiring diagrams

This page contains all the electrical diagrams for the component. ext tail fl dedicate drl lh, in which he is found in the car Kia K3 II facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram ext tail fl dedicate drl lh (1 of 2)

Wiring diagram ext tail fl dedicate drl lh for Kia K3 II facelift (2021-2024)

Get access

BLK WIRE BLU WIRE BRN WIRE CLOCKSPRING DEDICATE DRL RH EXT TAIL FL DEDICATE DRL LH FROM MULTI-FUSE 2 (DIAGRAM 1 OF 10) GLOVE BOX LAMP) GRN WIRE GRY WIRE H/LP HI RH H/LP LO LH ICU-A ICU-B ICU-C ICU-D ICU-E IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IPS CONTROL IPS CONTROL MODULE LAMP LOAD LEFT FRONT VANITY LAMP LEFT HEADLAMP LEFT HEADLAMP LAMP MEMORY POWER NCA WIRE ORG/ WIRE OVERHEAD CONSOLE LAMP PASSENGER POWER OUTSIDE MIRROR PNK WIRE RED WIRE RIGHT FRONT VANITY LAMP RIGHT HEADLAMP RIGHT REAR COMBINATION LAMP (OUT) RIGHT REAR TURN SIGNAL LAMP ROOM LAMP SPOC+ CONTROL STEERING HEAT STEERING WHEEL HEATER MODULE STEERING WHEEL STOP LP RH T/SIG FRT LH T/SIG RR RH TRUNK ROOM LAMP W/O SMART KEY WHT WIRE

Go to component: -> 1.6l turbo, power distribution circuit (4 of 10) -> EXT TAIL FL DEDICATE DRL LH

Wiring diagram ext tail fl dedicate drl lh (2 of 2)

Wiring diagram ext tail fl dedicate drl lh for Kia K3 II facelift (2021-2024)

Get access

BLK WIRE BLU WIRE BRN WIRE CLOCKSPRING DEDICATE DRL RH EXT TAIL FL DEDICATE DRL LH FROM MULTI-FUSE 2 (DIAGRAM 1 OF 10) GLOVE BOX LAMP) GRN WIRE GRY WIRE H/LP HI RH H/LP LO LH ICU-A ICU-B ICU-C ICU-D ICU-E IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IPS CONTROL IPS CONTROL MODULE LAMP LOAD LEFT FRONT VANITY LAMP LEFT HEADLAMP MEMORY POWER NCA WIRE ORG/ WIRE OVERHEAD CONSOLE LAMP PASSENGER POWER OUTSIDE MIRROR PNK WIRE RED WIRE RIGHT FRONT VANITY LAMP RIGHT HEADLAMP RIGHT REAR COMBINATION LAMP (OUT) RIGHT REAR TURN SIGNAL LAMP ROOM LAMP SPOC+ CONTROL STEERING HEAT STEERING WHEEL HEATER MODULE STEERING WHEEL STOP LP RH T/SIG FRT LH T/SIG RR RH TRUNK ROOM LAMP W/O SMART KEY WHT WIRE

Go to component: -> 2.0l, power distribution circuit (4 of 10) -> EXT TAIL FL DEDICATE DRL LH
