Kia K3 II facelift (2021-2024) bvs sply Wiring diagram

This page shows the only wiring diagram for the component.bvs sply, which is found in the car Kia K3 II facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram bvs sply (1 of 1)

Wiring diagram bvs sply for Kia K3 II facelift (2021-2024)

Get access

APS 1 SPLY APS 2 SIG APT SIG BATTERY SENS (LIN) BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/ORG WIRE BVS SPLY CCP-CAN HIGH CCP-CAN LOW CCV CTRL COMPUTER DATA E/R-A E/R-B E/R-D ECU 1 FUSE ECU 2 FUSE ENG CTRL RLY CTRL ENGINE CONTROL RELAY ENGINE RPM SIG FTP SENS SIG FUEL PUMP RLY CTRL FUEL TANK LVL GRN WIRE GRN/ORG WIRE GRY WIRE IGN COIL FUSE IMMO COMM LINE KNOCK SENS GND KNOCK SENS SIG KNOCK SENSOR LINES SYSTEM MAP SENS (IAT SIG) MAP SENS SIG NCA WIRE ORG/ WIRE OXYGEN SENSOR (UP) P-CAN HIGH P-CAN LOW PCB BLOCK PCSV CTRL PNK WIRE PURGE CONTROL SOLENOID VALVE RCV CTRL RED WIRE RPS SIG SENSOR 1 FUSE SENSOR 2 FUSE SENSOR 3 FUSE SENSOR SPLY TPS 2 SIG TPS GND TPS SPLY WHT WIRE YEL WIRE

Go to component: -> Wiring diagram engine performance 1.6l turbo (4 of 6) -> BVS SPLY
