Power windows circuit, w/ auto up/down power window for Kia K3 I facelift (2015-2018)
Power windows circuit, w/ auto up/down power window (1 of 3)
AUTO DOWN
AUTO UP UP
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
DRIVER WINDOW SWITCH
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-A
ILL
IPS CONTROL MODULE
LEFT POWER WINDOW RELAY
LEFT REAR POWER WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LH PWR WINDOW RELAY CONTROL
OFF
ORG/ WIRE
P/WDW LH FUSE
P/WDW RH FUSE
PASSENGER WINDOW SWITCH
PNK WIRE
PNK/BLK WIRE
POWER WINDOW MAIN SWITCH
RED WIRE
RH PWR WINDOW RELAY CONTROL
RIGHT POWER WINDOW RELAY
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
SMART JUNCTION BLOCK
WHT WIRE
WINDOW LOCK SWITCH
YEL WIRE
YEL/BLK WIRE
Power windows circuit, w/ auto up/down power window (2 of 3)
Power windows circuit, w/ auto up/down power window (3 of 3)
AUTO
AUTO DOWN DOWN
B+ GND
BCM (CENTER OF DASH)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
COM
DOOR LOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
DOWN UP
DRIVER SAFETY POWER WINDOW MODULE
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HALL EFFECT
ILL
MEMORY PWR COM
OFF
PASSENGER POWER WINDOW SWITCH
PASSENGER SAFETY POWER WINDOW MODULE
PNK WIRE
PNK/BLK WIRE
RELAY
REVERSE PROTECTION, FILTER
SAFETY PWR WINDOW ENABLE OUTPUT
SENSOR
SHUNT RESISTOR
SIG FILTER
UP AUTO UP
WHT WIRE
YEL WIRE
YEL/BLK WIRE
