Kia K3 I facelift (2015-2018) w/ smart key 2.0l gdi, 2.0l mpi 1.6l turbo wiring diagram
This page shows the only wiring diagram for the component.w/ smart key 2.0l gdi, 2.0l mpi 1.6l turbo, which is found in the car Kia K3 I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ smart key 2.0l gdi, 2.0l mpi 1.6l turbo wiring diagram (1 of 1)
AEB RADAR
BLK WIRE
BLOWER RELAY
BRAKE FLUID LEVEL SENSOR
BURGLAR ALARM HORN
CLUTCH SWITCH
COOLING FAN 2 RELAY
COOLING FAN CONTROLLER
COOLING FAN MOTOR
COOLING FAN RELAY
DYNAMIC BENDING LIGHT MODULE
ESC MODULE
EXTERNAL BUZZER
FRONT DEICER
HOOD SWITCH
HORN
I/P-B
IGNITION LOCK SWITCH
IPS CONTROL MODULE
LEFT FRONT FOG LAMP
LEFT HEADLAMP
M/T
MDPS UNIT
MULTI-PURPOSE CHECK CONNECTOR
NCA WIRE
OPT GND (DRL)
PDM 2 (ACC) RELAY
PTC HEATER
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SMART JUNCTION BLOCK
VACUUM PUMP
W/ BURGLAR ALARM
W/ SMART KEY 2.0L GDI, 2.0L MPI 1.6L TURBO
WASHER LEVEL SENSOR
WASHER MOTOR
WIPER MOTOR
Go to component -> Ground distribution circuit (5 of 6) -> W/ SMART KEY 2.0L GDI, 2.0L MPI 1.6L TURBO
