Kia K3 I facelift (2015-2018) p position ignition lock sw Wiring diagram
This page shows the only wiring diagram for the component.p position ignition lock sw, which is found in the car Kia K3 I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p position ignition lock sw (1 of 1)
A/T
A/T M/T
ACC/
ANTENNA GROUND PNK ANTENNA POWER WIRE
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE LIGHT SWITCH
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER TOGGLE BUTTON
EMS COM
ENGINE RPM SIGNAL
EXTERNAL BUZZER
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
GRY/ORG WIRE
IGNITION LOCK SWITCH
ILL
IMMO ANTENNA GROUND
IMMO ANTENNA POWER
IMMO IND
M/T
NCA WIRE
ORG/ WIRE
P POSITION IGNITION LOCK SW
P POSITION SWITCH
PASS TOGGLE BUTTON
PNK WIRE
RED WIRE
SMART KEY CONTROL MODULE (RIGHT END OF DASH)
SPORT MODE SWITCH
SSB (BLUE ON)
SSB (WHITE OFF)
SSB AMBER
SSB AMBER (ACC)
SSB GREEN (IGN)
SSB ILL GROUND
SSB ILL POWER
SSB SW 1
SSB SW 2
START FEEDBACK SIG
START STOP BUTTON SWITCH
STARTING/CHARGING SYSTEM
STOP LAMP POWER
WHEEL SPEED
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, w/ smart key system (3 of 3) -> P POSITION IGNITION LOCK SW
