Kia K3 I facelift (2015-2018) driver side impact sensor low Wiring diagram
This page shows the only wiring diagram for the component.driver side impact sensor low, which is found in the car Kia K3 I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side impact sensor low (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
DRIVER CURTAIN AIR BAG (HIGH)
DRIVER CURTAIN AIR BAG (LOW)
DRIVER EMERGENCY FASTENING DEVICE HIGH
DRIVER EMERGENCY FASTENING DEVICE LOW
DRIVER PRESSURE SIDE IMPACT HIGH
DRIVER PRESSURE SIDE IMPACT LOW
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT BELT PRETENSIONER HIGH
DRIVER SEAT BELT PRETENSIONER LOW
DRIVER SIDE AIR BAG (HIGH)
DRIVER SIDE AIR BAG (LOW)
DRIVER SIDE IMPACT SENSOR HIGH
DRIVER SIDE IMPACT SENSOR LOW
GRN WIRE
ORG/ WIRE
PASS CURTAIN AIR BAG HIGH
PASS CURTAIN AIR BAG LOW
PASS EMERGENCY FASTENING DEVICE HIGH
PASS EMERGENCY FASTENING DEVICE LOW
PASS PRESSURE SIDE IMPACT HIGH
PASS PRESSURE SIDE IMPACT LOW
PASS SEAT BELT BUCKLE SWITCH (-)
PASS SEAT BELT PRETENSIONER HIGH
PASS SEAT BELT PRETENSIONER LOW
PASS SIDE AIR BAG HIGH
PASS SIDE AIR BAG LOW
PASS SIDE IMPACT SENSOR HIGH
PASS SIDE IMPACT SENSOR LOW
PASSENGER CURTAIN AIR BAG
PASSENGER EMERGENCY FASTENING DEVICE
PASSENGER PRESSURE SIDE IMPACT SENSOR
PASSENGER SEAT BELT BUCKLE SWITCH
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE AIR BAG
PASSENGER SIDE IMPACT SENSOR
RED WIRE
SRS CONTROL MODULE (FRONT OF CENTER CONSOLE)
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> DRIVER SIDE IMPACT SENSOR LOW
