Tire pressure monitoring circuit for Kia Forte III facelift (2021-2024)

BLK WIRE BLU WIRE BRN WIRE C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES HOT IN ON OR START IBU IBU 1 FUSE ICU JUNCTION BLOCK ICU-E ICU-F INSTRUMENT CLUSTER INTERFACE LEFT FRONT TIRE PRESSURE SENSOR LEFT REAR TIRE PRESSURE SENSOR MEM PWR MICOM ON/START I/P P-CAN HIGH P-CAN LOW PNK/BLK WIRE RED WIRE RIGHT END OF DASH) RIGHT FRONT TIRE PRESSURE SENSOR RIGHT REAR TIRE PRESSURE SENSOR SEG LCD TFT LCD SIG 1 GND TPMS IND WHT WIRE YEL WIRE
