Kia Forte III facelift (2021-2024) tpms switch Wiring diagram
This page shows the only wiring diagram for the component.tpms switch, which is found in the car Kia Forte III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tpms switch (1 of 1)
2.0L
ABS 1 FUSE
ABS 2 FUSE
ABS 3 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
E/R-D
ESC MODULE
ESC OFF SWITCH
ESC UNIT
FL SIG
FL VCC
FR SIG
FR VCC
GRN WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
NCA WIRE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL SIG
RL VCC
RR SIG
RR VCC
STOP LAMP SW
TPMS SWITCH
VBATT
WARNING SYSTEMS
WHEEL SENS OUTPUT (FR)
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, w/o epb (1 of 2) -> TPMS SWITCH
