Kia Forte III facelift (2021-2024) position switch code d Wiring diagram
This page shows the only wiring diagram for the component.position switch code d, which is found in the car Kia Forte III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram position switch code d (1 of 1)
BLK WIRE
BLU WIRE
CCP-CAN HIGH
CCP-CAN LOW
CLUTCH 1 SPEED GROUND
CLUTCH 1 SPEED SUPPLY
CLUTCH 2 SPEED GROUND
CLUTCH 2 SPEED SUPPLY
CLUTCH SPEED SENSOR ASSEMBLY
COMPUTER DATA LINES SYSTEM
DCT 1 FUSE
DCT 2 FUSE
DOWN SHIFT
E/R JUNCTION BLOCK
E/R-D
EVEN SENSOR (CLUTCH 2)
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
MEMORY POWER
ODD SENSOR (CLUTCH 1)
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PNK ON/START INPUT PNK UP SHIFT WIRE
PNK SHIFT MTR 1 (ODD) HALL 2 WIRE
PNK WIRE
POSITION SWITCH CODE D
POSITION SWITCH CODE N
POSITION SWITCH CODE R
POSITION SWTICH CODE P
RED WIRE
RED/ORG WIRE
SHIFT MTR 1 (ODD) GND
SHIFT MTR 1 (ODD) HALL 1
SHIFT MTR 1 (ODD) HALL 3
SHIFT MTR 1 (ODD) SUPPLY
SHIFT MTR 2 (EVEN) HALL 2
SHIFT MTR 2 (EVEN) HALL 3
STARTING/CHARGING SYSTEM
TCM
TCU 1 FUSE
TCU 2 FUSE
TRANSAXLE RANGE SWITCH
WHT WIRE
YEL WIRE
Go to component -> 1.6l turbo, transmission circuit (1 of 3) -> POSITION SWITCH CODE D
