Kia Forte III (2018-2021) burglar alarm relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.burglar alarm relay ctrl, which is found in the car Kia Forte III (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram burglar alarm relay ctrl (1 of 1)
A/T
BATTERY
BATTERY JUNCTION BLOCK
BLK WIRE
BURGLAR ALARM RELAY
BURGLAR ALARM RELAY CTRL
CLUTCH SW
CLUTCH SWITCH
E/R JUNCTION BLOCK
GRN WIRE
GRN/BLK WIRE
GRY WIRE
IBU SSB
ICM RELAY BOX
ICU JUNCTION BLOCK
ICU-B
ICU-E
IGN LOCK SW
IGNITION LOCK SWITCH
IGNITION LOCK, CLUTCH SWITCH
IGNITION SWITCH
LOCK
M/T
MULTI FUSE 2
ORG/ WIRE
P/N SWITCH
PCM
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RLY
RLY SW CTRL INPUT
SSB
START 1 RELAY
START FUSE
START MOTOR
START SOLENOID
START/STOP BUTTON SWITCH
TRANSAXLE RANGE SWITCH
W/ SMART KEY
W/O SMART KEY
W/O SMART KEY W/ SMART KEY
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Starting circuit -> BURGLAR ALARM RELAY CTRL
