Kia Forte II facelift (2016-2018) serial comn glass status sig Wiring diagram
This page shows the only wiring diagram for the component.serial comn glass status sig, which is found in the car Kia Forte II facelift (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram serial comn glass status sig (1 of 1)
BCM
BLK WIRE
BRN WIRE
CLICK
CLOSE
CLOSE/ TILT DOWN
GLASS STATUS SIG/ SERIAL
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
I/P-E
I/P-G
MEMORY POWER
MODULE 5 FUSE
NCA WIRE
ON INPUT
ORG/ WIRE
OVERHEAD CONSOLE
PNK WIRE
SERIAL COMN GLASS STATUS SIG
SIG A
SIG B
SIG C
SMART JUNCTION BLOCK
SUNROOF (IN OVERHEAD CONSOLE)
SUNROOF FUSE
SUNROOF SWITCH
TILT UP
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> SERIAL COMN GLASS STATUS SIG
