Wiring diagram engine performance 1.6l turbo, electric oil pump circuit for Kia Forte II (2013-2016)
Wiring diagram engine performance 1.6l turbo, electric oil pump circuit
BLK WIRE
BLK/ORG WIRE
BRN WIRE
C-CAN HI
C-CAN LO
COMPUTER DATA LINES SYSTEM
E/R FUSE, RELAY BOX
HALL SIG U
HALL SIG V
HALL SIG W
HALL SNSR GND
HALL SNSR POWER
HOT AT ALL TIMES
HOT IN ON OR START
ISG INVERTER FUSE
MEMORY POWER
MOTOR POWER U
MOTOR POWER V
MOTOR POWER W
OIL PUMP ACTUATOR (LEFT FRONT OF TRANSAXLE)
OIL PUMP INVERTER (LEFT TOP OF DASH)
ON/START INPUT
PNK WIRE
RED WIRE
SHIELD GND
TCU FUSE
WHT WIRE
YEL WIRE
