Kia Forte II (2013-2016) seek seek mode up down Wiring diagram
This page shows the only wiring diagram for the component.seek seek mode up down, which is found in the car Kia Forte II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seek seek mode up down (1 of 1)
2 DOOR, 4 DOOR 5 DOOR
5 DOOR
ACC OUTPUT
AUDIO IN-
AUX DETECT
AUX L IN
AUX R IN
AUX, USB JACK
B+ (O/P)
B/T IN
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CAMERA GND
CAMERA PWR
CAMERA V GND
CAMERA VIDEO
CAR SHIELD
CLOCK SPRING (TOP OF STEERING COLUMN)
DRIVER DOOR SPEAKER
DRIVER TWEETER SPEAKER
GND (REF)
GRN WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
ILL
LEFT AUDIO (+) (-) REMOTE CONTROL SWITCH ILL
LEFT BLUETOOTH (+) (-) REMOTE CONTROL SWITCH CALL
MUTE
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
REARVIEW CAMERA (4 DOOR: LEFT CENTER OF TRUNK LID)
RED WIRE
SEEK SEEK MODE UP DOWN
STEERING WHEEL)
USB/IPOD D (-)
USB/IPOD GND
USB/IPOD VCC
VOICE END OF CALL
VOL VOL UP DOWN
W/O STEERING WHEEL HEATER W/ STEERING WHEEL HEATER
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, with navigation (2 of 2) -> SEEK SEEK MODE UP DOWN
