Kia Forte II (2013-2016) passenger power outside mirror turn lamp Wiring diagram
This page shows the only wiring diagram for the component.passenger power outside mirror turn lamp, which is found in the car Kia Forte II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger power outside mirror turn lamp (1 of 1)
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
C-CAN TRANSCEIVER
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR
DRIVER POWER OUTSIDE MIRROR TURN LAMP
EXCEPT LED
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HIGH MOUNTED STOP LAMP
INSTRUMENT CLUSTER
INTERFACE (W/ DOT LCD) LED DRIVER IC/INTERFACE (W/ TFT LCD)
JOINT CONNECTOR
LAMP
LED
LEFT "C" PILLAR)
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT TURN IND
MICOM
NCA WIRE
PASSENGER DOOR)
PASSENGER POWER OUTSIDE MIRROR TURN LAMP
PNK/BLK WIRE
QUARTER PANEL GROUND
REAR HMSL DEFOGGER CURRENT (2 DOOR)
RED/ORG WIRE
RIGHT LICENSE LAMP
RIGHT TURN IND
SIG GND 1
STOP
TAIL ON IND
TAILLAMP
WHT WIRE
Go to component -> Exterior lamps circuit (3 of 4) -> PASSENGER POWER OUTSIDE MIRROR TURN LAMP
