Kia Forte II (2013-2016) leak current auto cut device Wiring diagram
This page shows the only wiring diagram for the component.leak current auto cut device, which is found in the car Kia Forte II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leak current auto cut device (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
ESC MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-F
I/P-G
IPS CONTROL MODULE B-CAN
K LINE
LEAK CURRENT AUTO CUT DEVICE
LOW HIGH
MEMORY FUSE
MODULE 2 FUSE
MULTIPURPOSE CHECK CONNECTOR (LEFT FRONT OF ENGINE COMPT)
OIL PUMP INVERTER (W/ ISG) (LEFT TOP OF DASH)
ORG/ WIRE
RED WIRE
RED/ORG WIRE
RIGHT END OF DASH)
SMART JUNCTION BOX
VACUUM PUMP
WHT WIRE
Go to component -> Computer data lines circuit (3 of 3) -> LEAK CURRENT AUTO CUT DEVICE
