Kia Forte II (2013-2016) cmps 2 exhaust signal wiring diagram
This page shows the only wiring diagram for the component.cmps 2 exhaust signal, which is found in the car Kia Forte II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
cmps 2 exhaust signal wiring diagram (1 of 1)
AIR TEMP INPUT
BATTERY SENSOR
BATTERY SNSR GND
BATTERY SNSR SIG
BATTERY SNSR V IN
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CKPS GND
CKPS SIG
CMPS 1 INTAKE GND
CMPS 1 INTAKE SIGNAL
CMPS 2 EXHAUST GND
CMPS 2 EXHAUST SIGNAL
DC MOTOR OUTPUT (-)
ECTS GND
ECTS SIGNAL
ELECTRICAL LOAD SIGNAL
ENGINE COOLANT TEMPERATURE SENSOR
ETC MOTOR, +/-
GRN WIRE
GROUND
GRY WIRE
HEATER
IGN CYL 1 W/O IMMO IGN CYL 4 W/ IMMO
IGN CYL 2 W/O IMMO IGN CYL 3 W/ IMMO
IGN CYL 3 W/O IMMO IGN CYL 2 W/ IMMO
IGN CYL 4 W/O IMMO IGN CYL 1 W/ IMMO
INJECTOR 3 CTRL
KNOCK SNSR GND
KNOCK SNSR SHIELD GND
KNOCK SNSR SIG
MAP SENSOR (LEFT REAR OF ENGINE)
OCV 1 CTRL (INTAKE)
OCV 2 CTRL (EXHAUST)
ORG/ WIRE
PCSV CTRL
PNK WIRE
PNK/BLK WIRE
POWER
PWM CTRL OUTPUT
RED WIRE
RED/ORG WIRE
SIGNAL
START SW INPUT
STARTING/CHARGING SYSTEM
TEMP
TPS 1 SIGNAL
TPS 2 SIGNAL
TPS GROUND
TPS SUPPLY
V OUT
VARIABLE CHARGE MOTION ACTUATOR
VCM GROUND
VCM SIG
VDD
VIP
VISV CTRL
VRC
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l, mfi control circuit, m/t (1 of 5) -> CMPS 2 EXHAUST SIGNAL
