Kia Forte II (2013-2016) 8 9 15 b-can high b-can low rear defogger Wiring diagram

1.6L TURBO A/T 1.6L TURBO M/T 2.0L 4 DOOR 5 DOOR 4 DOOR, 5 DOOR 2 DOOR 5 DOOR 8 9 15 B-CAN HIGH B-CAN LOW REAR DEFOGGER A/C CONTROL MODULE AUTOMATIC A/C MANUAL A/C B-CAN LOW BCM (CENTER OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DEFOGGER DEICER FUSE DRIVER DOOR E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT) FRONT DEICER FRT DEICER RLY CTRL GND REAR DEFOGGER SWITCH GRN WIRE GRY WIRE HMSL CURRENT HOT AT ALL TIMES HTD MIRR FUSE I/P-A I/P-B I/P-F I/P-G ICM RELAY BOX (REAR OF SMART JUNCTION BOX) FRONT DEICER RELAY IND IPS CONTROL MODULE JOINT CONNECTOR MULTI FUSE NCA WIRE OFF ORG/ WIRE PASSENGER DOOR) PASSENGER POWER OUTSIDE MIRROR DRIVER POWER OUTSIDE MIRROR DEFOGGER PNK 2 DOOR 4 DOOR, 4 5 WIRE PNK 2 DOOR 4 DOOR, 5 DOOR 4 5 WIRE PNK WIRE QUARTER PANEL GROUND QUARTER PANEL GROUND (4 DOOR) REAR DEFOGGER RED WIRE RR HTD B-CAN RLY CTRL HIGH RR HTD FUSE RR HTD RELAY SMART JUNCTION BOX (LEFT END OF DASH) SWITCH INPUT WHT WIRE
