Kia Forte I (2008-2013) Tire pressure monitoring circuit

BLK WIRE BLU WIRE C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER C-CAN HI C-CAN LO DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM HIGH LOW HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX (LEFT SIDE OF DASH) I/P-C IND INSTRUMENT CLUSTER MEMORY PWR MICOM ON/START IN ORG/ WIRE POWER CONNECTOR RED WIRE ROOM LP FUSE TIRE PRESSURE MONITORING MODULE (RIGHT SIDE OF DASH) TPMS TREAD WHT WIRE
