Kia Forte I (2008-2013) snsr 2 fuse Wiring diagrams
This page contains all the electrical diagrams for the component. snsr 2 fuse, in which he is found in the car Kia Forte I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram snsr 2 fuse (1 of 4)
54 43 57 CHG-K SIGNAL POWER GND
A/C COMPRESSOR
A/C CONTROL MODULE
A/C PRESSURE TRANSDUCER (RIGHT REAR OF ENGINE COMPT)
A/C RELAY CONTROL
A/C SW INPUT A/C PRESSURE
A/CON FUSE
A/CON RELAY
AMBIENT SENSOR (FRONT BUMPER FRAME)
ASIC
AUTO LIGHT, PHOTO SENSOR (CENTER OF DASH)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BLWR MAX SIG
BRN/ORG WIRE
C/FAN (HI) RLY CTRL
C/FAN FUSE
C/FAN HI RELAY
C/FAN LO RELAY
COOLING FAN MOTOR (BEHIND RADIATOR)
ECM/TCM (LEFT REAR OF ENGINE COMPT)
ECU FUSE
EMS BOX (ENGINE COMPT)
ENGINE CONTROL
ENGINE CONTROLS SYSTEM
ENGINE CTRL 64 65 RLY CTRL C/FAN LO RLY CTRL CHG-K 57 42
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ENGINE CONTROL RELAY ENERGIZED
INJECTOR FUSE
INSTRUMENT CLUSTER
MULTI FUSE
NCA WIRE
ORG/ WIRE
PNK 6 7 WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RELAY
SENDER ENGINE COOLANT TEMPERATURE SENSOR, SENDER (REAR OF ENGINE)
SENSOR
SIG
SIGNAL GROUND
SNSR 2 FUSE
SW INPUT (THERMO) CHGAT
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> SNSR 2 FUSE
Wiring diagram snsr 2 fuse (2 of 4)
ALT FUSE
BLK WIRE
BLU WIRE
C/FAN (HI) RLY CTRL
C/FAN FUSE
C/FAN HI RELAY
C/FAN LO RELAY
C/FAN LO RLY CTRL
CHG-K
COOLING FAN MOTOR (BEHIND RADIATOR)
E/R FUSE, RELAY BOX (LEFT REAR OF ENGINE COMPT)
ECM/TCM (LEFT REAR OF ENGINE COMPT)
ECU FUSE
EMS BOX (ENGINE COMPT)
ENGINE CONTROL
ENGINE CTRL RLY CTRL
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
MULTI FUSE
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RELAY
SENDER ENGINE COOLANT TEMPERATURE SENSOR, SENDER (REAR OF ENGINE)
SENSOR
SIGNAL GROUND
SNSR 2 FUSE
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Cooling fan circuit -> SNSR 2 FUSE
Wiring diagram snsr 2 fuse (3 of 4)
69 75 IMMO IND IMMO DL
ANTENNA COIL
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
CHG-K
ECM (LEFT REAR OF ENGINE COMPARTMENT)
EMS BOX (ENGINE COMPT)
GRY WIRE
HOT AT ALL TIMES I/P JUNCTION ROOM BOX LP FUSE (LEFT SIDE OF DASH)
HOT W/ ENGINE CONTROL RELAY ENERGIZED
I/P-C
IGNITION KEY ILL, DOOR WARNING SWITCH
IMMOBILIZER IND
IMMOBILIZER MODULE (NEAR STEERING COLUMN)
INSTRUMENT CLUSTER
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK 1 2 3 4 5 ANTENNA+ ANTENNA- GROUND B+ K-LINE WIRE
PNK WIRE
POWER CONNECTOR
SNSR 2 FUSE
WHT WIRE
YEL WIRE
Go to component -> Immobilizer circuit, without smart key system -> SNSR 2 FUSE
Wiring diagram snsr 2 fuse (4 of 4)
A/C COMPRESSOR (FRONT OF ENGINE)
A/C PRESSURE TRANSDUCER (RIGHT REAR OF ENGINE COMPT)
A/C RELAY CONTROL
A/C SW INPUT A/C PRESSURE
A/CON FUSE
A/CON RELAY
BLK WIRE
BLU WIRE
BLWR MOTOR MAX SW INPUT
BRN/ORG WIRE
C/FAN (HI) RLY CTRL
C/FAN FUSE
C/FAN HI RELAY
C/FAN LO RELAY
COOLING FAN MOTOR (BEHIND RADIATOR)
ECM, TCM (LEFT REAR OF ENGINE COMPT)
ECU FUSE
EMS BOX (ENGINE COMPT)
ENGINE CONTROL
ENGINE CONTROLS SYSTEM
ENGINE CTRL 64 65 RLY CTRL C/FAN LO RLY CTRL CHG-K 57 42
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ENGINE CONTROL RELAY ENERGIZED
INJECTOR FUSE
INSTRUMENT CLUSTER
MULTI FUSE
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RELAY
SENDER ENGINE COOLANT TEMPERATURE SENSOR, SENDER (REAR OF ENGINE)
SENSOR
SIGNAL GROUND
SNSR 2 FUSE
SW INPUT (THERMO) CHG-A 54 43 57 CHG-K SIGNAL POWER GND
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Manual a/c circuit (2 of 2) -> SNSR 2 FUSE
