Kia Forte I (2008-2013) sig sig wiring diagram
This page shows the only wiring diagram for the component.sig sig, which is found in the car Kia Forte I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sig sig wiring diagram (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
BUCKLE BUCKLE WARN GROUND SIGNAL G+ G-
CENTER CONSOLE
CLOCK- SPRING
DRIVER AIR BAG
DRIVER ANCHOR PRETENSIONER
DRIVER PASSENGER SIDE AIR BAG 2 AIR BAG (RIGHT SIDE (DRIVER OF DASH) SEAT FRAME)
DRIVER PRESSURE SIDE IMPACT SENSOR
DRIVER SEAT BELT BUCKLE SWITCH
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HI LO
LO HI
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER AIR BAG 1 (RIGHT SIDE DRIVER OF DASH) AIR BAG
PASSENGER ANCHOR PRETENSIONER
PASSENGER PRESSURE SIDE IMPACT SENSOR
PNK WIRE
PNK/BLK WIRE
RED WIRE
SIG SIG
STEERING WHEEL)
WARN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> SIG SIG
