Kia Forte I (2008-2013) room lamp fuse Wiring diagram
This page shows the only wiring diagram for the component.room lamp fuse, which is found in the car Kia Forte I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram room lamp fuse (1 of 1)
B-CAN TRANSCEIVER
BCM
BLK WIRE
BLU WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
FR FOG RLY CTRL
FR FOG SW IN
FRONT FOG
FRONT FOG HIGH LAMP BEAM IND IND (W/ (W/ ANALOG) ANALOG)
GRN WIRE
GRN/ORG WIRE
H/LP (HI) RLY CTRL
H/LP LO RLY CTRL
HEAD LAMP FUSE
HEAD LP SW
HIGH BEAM IND (W/ SUPER- VISION) MICOM
HIGH LOW
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
I/P JUNCTION BOX (LEFT SIDE OF DASH)
I/P-C
I/P-D
I/P-G
I/P-H
INSTRUMENT CLUSTER
LAMP IND (W/ SUPERVISION)
LEFT FRONT FOG LAMP
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
POWER CONNECTOR
RED WIRE
RED/BLK WIRE
RIGHT FRONT FOG LAMP
RIGHT TAIL LP FUSE
ROOM LAMP FUSE
TAIL LAMP RELAY
TAIL LP RLY CTRL
TAIL LP SW IN CAN HIGH CAN LOW
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit, without drl (1 of 2) -> ROOM LAMP FUSE
