Kia Forte I (2008-2013) pnk vcm sens Wiring diagrams
This page contains all the electrical diagrams for the component. pnk vcm sens, in which he is found in the car Kia Forte I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk vcm sens (1 of 2)
46 47 48 49 50 CHG-K ALTERNATOR (COM)
BATTERY PWR WHEEL SPD INPUT (+)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
CANISTER CLOSE VALVE (FRONT OF FUEL TANK)
CKPS GND VEHICLE SPD INPUT
CKPS SENS LINEAR LAMBDA SENS VIP LINEAR LAMBDA SENS VN LINEAR LAMBDA SENS VG
CRANKSHAFT POSITION SENSOR (REAR OF ENGINE)
ECM (LEFT REAR OF ENGINE COMPT)
ECU 1 FUSE FUSE
EMS BOX (ENGINE COMPT)
ENGINE CONTROL RELAY
FUEL TANK LVL SENS
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
INJECTOR FUSE
INJECTORS (ON INTAKE MANIFOLD)
KNOCK SENS SIG APS 2 GND ECTS GND CMP (EXHAUST) SENS
NCA WIRE
ORG BLK WIRE
ORG/ WIRE
OXYGEN SENSOR (UP) (REAR OF ENGINE)
PNK LINEAR LAMBDA SENS VRC FTPS SUPPLY VCM GND WIRE
PNK VCM SENS WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
SNSR 1 FUSE
STARTING/ CHARGING SYSTEM
TO ECU 2 FUSE (DIAGRAM
TO IGN COIL FUSE (DIAGRAM
VARIABLE INTAKE SOLENOID VALVE
VIS VALVE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l (1 of 6) -> PNK VCM SENS WIRE
