Kia Forte I (2008-2013) ind c-can lo on/start in wiring diagram
This page shows the only wiring diagram for the component.ind c-can lo on/start in, which is found in the car Kia Forte I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ind c-can lo on/start in wiring diagram (1 of 1)
BATTERY PWR
BLK WIRE
BLK/ORG WIRE
C-CAN HI
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
EPS +
EPS CONTROL MODULE
HOT AT ALL TIMES
HOT AT ALL TIMES E/R FUSE, RELAY BOX
I/P JUNCTION BOX
I/P-B
I/P-C
IGN 1-A FUSE
IND C-CAN LO ON/START IN
INSTRUMENT CLUSTER
MDPS (LEFT REAR OF ENGINE COMPT) FUSE FUSE
MULTI-
ORG/ WIRE
WHT WIRE
YEL/ORG WIRE
Go to component -> Electronic power steering circuit -> IND C-CAN LO ON/START IN
