Kia Forte I (2008-2013) a/c control module rear defogger switch wiring diagram
This page shows the only wiring diagram for the component.a/c control module rear defogger switch, which is found in the car Kia Forte I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
a/c control module rear defogger switch wiring diagram (1 of 1)
5 DOOR
A/C CONTROL MODULE REAR DEFOGGER SWITCH
AUTO A/C MANUAL A/C
BCM (CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN/ORG WIRE
DEFOGGER
DRIVER DOOR
DRIVER POWER OUTSIDE MIRROR
E/R FUSE, RELAY BOX (LEFT REAR OF ENGINE COMPT)
ENGINE RUNNING INPUT
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HTD GLASS
I/P JUNCTION BOX (LEFT SIDE OF DASH)
I/P-B
I/P-F
I/P-G
IND
JOINT CONNECTOR
MIRR HTD FUSE
MULTI FUSE
NCA WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
REAR DEFOGGER
REAR DEFOGGER RELAY
REAR DEFOGGER RELAY CTRL
REAR DEFOGGER SWITCH INPUT
RED WIRE
RED/BLK WIRE
STARTING/ CHARGING SYSTEM
WHT/BLK WIRE
Go to component -> Rear defogger & heated mirrors circuit -> A/C CONTROL MODULE REAR DEFOGGER SWITCH
