Kia Forte I (2008-2013) 9 21 key solenoid shift lock Wiring diagram
This page shows the only wiring diagram for the component.9 21 key solenoid shift lock, which is found in the car Kia Forte I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 9 21 key solenoid shift lock (1 of 1)
"P" POSITION SW
5 11 10 "P" INPUT "N" INPUT "D" INPUT PNK WIRE
9 21 KEY SOLENOID SHIFT LOCK
A/T
ATM LEVER ILL
BLK WIRE
BLU WIRE
BRN WIRE
D OUT
DOWN SHIFT
GRN WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX (LEFT SIDE OF DASH)
I/P-B
INSTRUMENT CLUSTER
KEY SOLENOID
N OUT
ORG/ WIRE
P OUT
PARKING POSITION SWITCH
PNK WIRE
R - OUT
RED WIRE
RED/BLK WIRE
SELECT SWITCH
SHIFT LOCK SOLENOID
SMART KEY CONTROL MODULE (RIGHT REAR OF TRUNK AREA)
SOLENOID
SPORT MODE
STOP LAMP RELAY (BEHIND LEFT CENTER OF DASH)
STOP LAMP SWITCH (BRAKE PEDAL ASSEMBLY)
STOP LP FUSE
SWITCH
TRANSMISSIONS SYSTEM
UP SHIFT
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> 9 21 KEY SOLENOID SHIFT LOCK
