Kia EV6 I (2021-2024) w/o hv battery ptc Wiring diagrams
This page contains all the electrical diagrams for the component. w/o hv battery ptc, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o hv battery ptc (1 of 2)
A/C PTC HEATER
A/COMP FUSE
ASSEMBLY (DIAGRAM 1 OF 21)
ASSEMBLY (DIAGRAM 2 OF 21)
ASSEMBLY (DIAGRAM 3 OF 21)
BATT HTR FUSE
BATT HTR RELAY
BLK WIRE
BLU WIRE
BMS PTC HEATER
BUS BAR
FROM BATTERY SYSTEM
FRONT HIGH VOLTAGE JUNCTION BLOCK
GRY WIRE
INNER HTR FUSE
INTER LOCK
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
TERMINAL BLOCK
TO BATTERY SYSTEM
TO FRONT INVERTER (DIAGRAM 16 OF 21)
W/ HV BATTERY PTC
W/O HV BATTERY PTC
YEL WIRE
Go to component -> Wiring diagram engine performance electric, long range (21 of 21) -> W/O HV BATTERY PTC
Wiring diagram w/o hv battery ptc (2 of 2)
A/C PTC HEATER
A/COMP FUSE
ASSEMBLY (DIAGRAM 1 OF 19)
ASSEMBLY (DIAGRAM 2 OF 19)
ASSEMBLY (DIAGRAM 3 OF 19)
BATT HTR FUSE
BATT HTR RELAY
BLK WIRE
BLU WIRE
BMS PTC HEATER
BUS BAR
FROM BATTERY SYSTEM
FRONT HIGH VOLTAGE JUNCTION BLOCK
GRY WIRE
INNER HTR FUSE
INTER LOCK
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
TERMINAL BLOCK
TO BATTERY SYSTEM
TO FRONT INVERTER (DIAGRAM 14 OF 19)
W/ HV BATTERY PTC
W/O HV BATTERY PTC
YEL WIRE
Go to component -> Wiring diagram engine performance electric, standard (19 of 19) -> W/O HV BATTERY PTC
