Kia EV6 I (2021-2024) video camera Wiring diagram
This page shows the only wiring diagram for the component.video camera, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram video camera (1 of 1)
12.3 INCH TFT
AVNT HEAD UNIT
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BUCK-
BVM SVM
CENTER OF FRONT BUMPER FASCIA)
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
CONVERTER)
DRIVER OUTSIDE MIRROR UNIT
E-CAN
FRONT VIEW CAMERA (SVM)
GROUND
GRY WIRE
INPUT
INSTRUMENT CLUSTER
LEFT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
LEFT PARKING DISTANCE WARNING REVERSE SENSOR
LEFT SIDE PARKING DISTANCE WARNING REVERSE SENSOR
MCU
NCA WIRE
PASSENGER OUTSIDE MIRROR UNIT
PNK WIRE
POWER
RED WIRE
RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT PARKING DISTANCE WARNING REVERSE SENSOR (SIDE)
SIGNAL
TAILGATE OUTER SWITCH
TRANSCEIVER/
VIDEO CAMERA
VIDEO+
W/ GT-LINE W/O GT-LINE
Go to component -> Parking assistant circuit, w/ adas (2 of 2) -> VIDEO CAMERA
