Kia EV6 I (2021-2024) upper console cover switch Wiring diagrams
This page contains all the electrical diagrams for the component. upper console cover switch, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram upper console cover switch (1 of 4)
ACC/ON INPUT
AVNT HEAD UNIT
AVNT KEYBOARD
B-CAN B-CAN LOW HIGH
BLK WIRE
BLK/ORG WIRE
BLU WIRE
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
CONTROL
GRN WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
HOT W/
HOT W/ ACC RELAY ENERGIZED
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-A
ICU-C
ICU-F
ICU-H
ILL
ILL (-) M-CAN LOW
INSTRUMENT CLUSTER MONITOR GND
INSTRUMENT CLUSTER MONITOR PWR
INSTRUMENT CLUSTER MONITOR VIDEO
IPS CONTROL MODULE
KEYBOARD GND
KEYBOARD POWER
LT GRN WIRE
M-CAN HIGH
M-CAN LOW
MAIN RELAY ENERGIZED
MEMORY POWER
MODULE 2 FUSE
MODULE 5 FUSE
MULTI MEDIA FUSE
ON/START INPUT
ORG/ WIRE
PNK WIRE
POWER
RED WIRE
RESET+
SVM SWITCH (W/ SVM) RVM SWITCH (W/O SVM)
UPPER CONSOLE COVER SWITCH
W/ SVM
W/O SVM
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, w/ amplifier (1 of 7) -> UPPER CONSOLE COVER SWITCH
