Kia EV6 I (2021-2024) tailgate full lock Wiring diagram
This page shows the only wiring diagram for the component.tailgate full lock, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate full lock (1 of 1)
BLK WIRE
BLU WIRE
CHILD LOCK FUSE
CHILD LOCK RELAY
CHILD LOCK RLY CTRL
CHILD LOCK SWITCH
CHILD UNLOCK RELAY
CHILD UNLOCK RLY CTRL
DEFOGGER RLY CTRL
DEFOGGER SYSTEM
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR LOCK RLY CTRL
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOOR UNLOCK RELAY
DOOR UNLOCK RLY CTRL
GRN WIRE
GRY WIRE
HEATER (NTC) (-)
HMSL
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-C
ICU-D
ICU-E
ICU-F
ICU-G
IND SWITCH
IPS CONTROL MODULE
IPS CTRL
LEFT RIGHT
LEFT STOP LAMP
LONG TERM LOAD LATCH RELAY
LONG TERM LOAD LATCH RLY CTRL
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT STOP LAMP
SEATS SYSTEM
STEERING WHEEL HEATING SWITCH
STEERING WHEEL)
STOP LAMP SIG
TAILGATE FULL LOCK
TAILGATE FULL OPEN SW
TAILGATE HANDLE SW SW
TAILGATE OPEN FUSE
TAILGATE RELEASE RELAY
TRUNK RLY CTRL
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TWO TURN UNLOCK RELAY
TWO TURN UNLOCK RLY CTRL
WHT WIRE
YEL WIRE
Go to component -> Ips control module circuit (2 of 2) -> TAILGATE FULL LOCK
