Kia EV6 I (2021-2024) motor resolver Wiring diagrams
This page contains all the electrical diagrams for the component. motor resolver, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram motor resolver (1 of 2)
BLK WIRE
BLK/ORG WIRE
BLU/ORG WIRE
BRN WIRE
BUS BAR
COMPUTER
DATA LINES
FRONT INVERTER (FRONT OF PE MODULE)
FRONT TRACTION MOTOR (FRONT MOTOR COMPT)
G-CAN HIGH
G-CAN LOW
GRN WIRE
GROUND
MOTOR RESOLVER
MOTOR RESOLVER SHIELD
MOTOR TEMP GND
MOTOR TEMP SHIELD
MOTOR TEMP SIGNAL
NCA WIRE
ON/START INPUT
RED WIRE
SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 3) -> MOTOR RESOLVER
Wiring diagram motor resolver (2 of 2)
BLK WIRE
BLK/ORG WIRE
BRN WIRE
BUS BAR
COMPUTER DATA LINES SYSTEM
FRONT INVERTER (FRONT OF FRONT PE MODULE)
FRONT TRACTION MOTOR (FRONT MOTOR COMPT)
G-CAN HIGH
G-CAN LOW
GRN WIRE
GROUND
ICU JUNCTION BLOCK
ICU-A
ICU-C
MAIN RELAY ENERGIZED
MODULE 4 FUSE
MOTOR RESOLVER
MOTOR RESOLVER SHIELD
MOTOR TEMP GND
MOTOR TEMP SHIELD
MOTOR TEMP SIGNAL
NCA WIRE
ON/START INPUT
P/B-D
PCB BLOCK
PNK WIRE
REAR INVERTER (LEFT SIDE OF REAR PE MODULE)
REAR TRACTION MOTOR (LEFT REAR OF REAR PE MODULE)
RED WIRE
RELAY ENERGIZED
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Transmission circuit (3 of 3) -> MOTOR RESOLVER
