Kia EV6 I (2021-2024) ips control b-can high Wiring diagram
This page shows the only wiring diagram for the component.ips control b-can high, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ips control b-can high (1 of 1)
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
BUTTON TYPE
COMPUTER DATA LINES SYSTEM
CONSOLE FLOOR SWITCH
CONSOLE UPPER COVER SWITCH
GRN WIRE
GRY WIRE
ICU JUNCTION BLOCK
ICU-F
ICU-H
ILL
IMS SWITCH
IPS CONTROL B-CAN HIGH
IPS CONTROL MODULE
LEFT REAR POWER WINDOW SWITCH
MAIN GND
ORG/ WIRE
PASSENGER POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW SWITCH
SMART PHONE WIRELESS CHARGER INDICATOR
TOUCH TYPE
UNIVERSAL ISLAND USB CHARGER CONNECTOR
W/ AUTO UP/DOWN, SAFETY
W/O AUTO UP/DOWN, SAFETY
Go to component -> Instrument illumination circuit (2 of 3) -> IPS CONTROL B-CAN HIGH
