Kia EV6 I (2021-2024) hot w/ long load latch relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ long load latch relay energized, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ long load latch relay energized (1 of 1)
B-CAN HIGH
B-CAN LOW
BCW IND
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DRIVER DOOR MODULE
DRIVER OUTSIDE MIRROR UNIT
FOLDING MOTOR
GRN WIRE
GRY/BLK WIRE
HOT W/
HOT W/ LONG LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-A
ILL
MCU
MIRR DOWN
MIRR LEFT
MIRR RH
MIRR SELECT L
MIRR SELECT R
MIRR UP
MODULE 1 FUSE
MODULE 3 FUSE
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR
PASSENGER OUTSIDE MIRROR UNIT
PNK WIRE
PNK/BLK WIRE
RED WIRE
SIDE VIEW CAMERA
SMART CONNECTOR
TURN LAMP
VIDEO SIGNAL
Go to component -> Memory mirrors circuit -> HOT W/ LONG LOAD LATCH RELAY ENERGIZED
