Kia EV6 I (2021-2024) heater pad Wiring diagram
This page shows the only wiring diagram for the component.heater pad, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heater pad (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CLOCKSPRING
CONSOLE FLOOR SWITCH
CTRL
GRN WIRE
GRY WIRE
HEATER PAD
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-F
ICU-G
ILL
IPS CONTROL MODULE
MULTI FUSE 3
NCA WIRE
NTC-
ORG/ WIRE
P/R JUNCTION BLOCK
PNK WIRE
PWR
RED WIRE
STEERING
STEERING WHEEL HEATED MODULE
STEERING WHEEL HEATER NTC (-)
STEERING WHEEL HEATER SW IND
STEERING WHEEL HEATER SW SIG
STEERING WHEEL HEATER SWITCH
STEERING WHEEL)
W/ BUTTON
W/ TOUCH
WHEEL HEATER NTC (+)
WHT WIRE
Go to component -> Heated steering wheel circuit -> HEATER PAD
