Kia EV6 I (2021-2024) encoder sens pwr pwm communication from scu gnd Wiring diagram
This page shows the only wiring diagram for the component.encoder sens pwr pwm communication from scu gnd, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram encoder sens pwr pwm communication from scu gnd (1 of 1)
B+ INPUT
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRAKE SWITCH FUSE
BRN WIRE
COMPUTER DATA LINES SYSTEM
E-SHIFTER 1 FUSE
E-SHIFTER 2 FUSE
E-SHIFTER 3 FUSE
E-SHIFTER RELAY
ENCODER A
ENCODER B PWM COMMUNICATION FROM VCU
ENCODER SENS GND
ENCODER SENS PWR PWM COMMUNICATION FROM SCU GND
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
ICU JUNCTION BLOCK
ICU-A
ICU-C
ICU-F
ICU-G
IEB UNIT
IPS CONTROL MODULE
K LINE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
P/R JUNCTION BLOCK
PNK WIRE
RED WIRE
RED/BLK WIRE
SCU (LEFT END OF DASH)
STOP LAMP SIG
STOP LAMP SIGNAL
STOP LAMP SWITCH
U PHASE
V PHASE
W PHASE ACTUATOR RELAY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Shift interlock circuit (1 of 2) -> ENCODER SENS PWR PWM COMMUNICATION FROM SCU GND
