Kia EV6 I (2021-2024) driver safety power module Wiring diagram
This page shows the only wiring diagram for the component.driver safety power module, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver safety power module (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MODULE
DRIVER DOOR MOOD LAMP
DRIVER DOOR OUTSIDE HANDLE
DRIVER LUMBAR SUPPORT MOTOR
DRIVER MANUAL SEAT SWITCH
DRIVER OUTSIDE MIRROR UNIT
DRIVER POWER SEAT MODULE
DRIVER POWER SEAT SWITCH
DRIVER SAFETY POWER MODULE
DRIVER SEAT USB CHARGER
GRN WIRE
GRN/BLK WIRE
GRY WIRE
ICU-A
IMS SWITCH
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR DOOR MOOD LAMP
LEFT REAR DOOR OUTSIDE HANDLE FLUSH ACTUATOR
NCA WIRE
TWO TURN UNLOCK RELAY
W/ MEMORY
W/ POWER SEAT
W/ RELAX SEAT
W/O MEMORY
W/O RELAX SEAT
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 7) -> DRIVER SAFETY POWER MODULE
