Kia EV6 I (2021-2024) door lk ind Wiring diagrams
This page contains all the electrical diagrams for the component. door lk ind, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door lk ind (1 of 2)
AJAR
B-CAN HIGH
B-CAN LOW
BLK WIRE
BRN WIRE
CENTRAL DOOR LOCK SWITCH
CENTRAL DOOR UNLOCK SWITCH
COMPUTER DATA LINES SYSTEM
DOOR
DOOR LK
DOOR LK IND
DOOR LK SW
DOOR LOCK IND
DOOR LOCK SWITCH
DOOR UNLK SW
DOOR UNLOCK SWITCH
DRIVER DOOR LK/UNLK SIG
DRIVER DOOR LOCK ACTUATOR (REAR OF DRIVER'S DOOR)
DRIVER DOOR MODULE
DRIVER DOOR SW
GRN WIRE
GRY WIRE
HOOD SWITCH
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-A
ICU-E
IEB UNIT
IPS CONTROL MODULE
MCU
MODULE 1 FUSE
MODULE 3 FUSE
ORG/ WIRE
PASSENGER POWER WINDOW SWITCH
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY ENERGIZED
UNLK
WHT WIRE
Go to component -> Anti-theft circuit (4 of 5) -> DOOR LK IND
Wiring diagram door lk ind (2 of 2)
AJAR
B-CAN HIGH
B-CAN LOW
BLK WIRE
BRN WIRE
CENTRAL DOOR LOCK SWITCH
CENTRAL DOOR UNLOCK SWITCH
COMPUTER DATA LINES SYSTEM
DOOR
DOOR LK
DOOR LK IND
DOOR LK SW
DOOR LOCK IND
DOOR LOCK SWITCH
DOOR UNLK SW
DOOR UNLOCK SWITCH
DRIVER DOOR LK/UNLK SIG
DRIVER DOOR LOCK ACTUATOR (REAR OF DRIVER'S DOOR)
DRIVER DOOR MODULE
DRIVER DOOR SW
GRN WIRE
GRY WIRE
HOOD SWITCH
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-A
ICU-E
IEB UNIT
IPS CONTROL MODULE
MCU
MODULE 1 FUSE
MODULE 3 FUSE
ORG/ WIRE
PASSENGER POWER WINDOW SWITCH
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY ENERGIZED
UNLK
WHT WIRE
Go to component -> Power door locks circuit (4 of 5) -> DOOR LK IND
