Kia EV6 I (2021-2024) charger lock relay Wiring diagrams

This page contains all the electrical diagrams for the component. charger lock relay, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram charger lock relay (1 of 4)

Wiring diagram charger lock relay for Kia EV6 I (2021-2024) (1 of 4)

Get access

ACC RELAY BLK WIRE BLK/ORG WIRE BRAKE FLUID LEVEL SENSOR CHARGER LOCK RELAY CHARGER UNLOCK RELAY COOLING FAN MOTOR ELECTRONIC A/C COMPRESSOR ELECTRONIC WATER PUMP 2 EXTERNAL BUZZER FRONT ELECTRONIC OIL PUMP FRONT INVERTER HOOD SWITCH HORN (HIGH) HORN (LOW) LEFT ACTIVE AIR FLAP UNIT LEFT CENTER PARKING DISTANCE WARNING FORWARD SENSOR LEFT FRONT CORNER RADAR LEFT HEADLAMP LEFT PARKING DISTANCE WARNING FORWARD SENSOR LEFT SIDE PARKING DISTANCE WARNING FORWARD SENSOR MDPS UNIT P/B-C P/R JUNCTION BLOCK PCB BLOCK POWER OUTLET RELAY RIGHT ACTIVE AIR FLAP UNIT RIGHT CENTER PARKING DISTANCE WARNING FORWARD SENSOR RIGHT END OF DASH) RIGHT FRONT CORNER RADAR RIGHT PARKING DISTANCE WARNING FORWARD SENSOR RIGHT SIDE PARKING DISTANCE WARNING FORWARD SENSOR SMART CRUISE CONTROL RADAR STOP LAMP SWITCH VESS UNIT WIPER HIGH RELAY WIPER LOW RELAY WIPER MOTOR

Go to component -> Ground distribution circuit (2 of 7) -> CHARGER LOCK RELAY

Wiring diagram charger lock relay (2 of 4)

Wiring diagram charger lock relay for Kia EV6 I (2021-2024) (2 of 4)

Get access

AMS FUSE BATTERY FUSE BLOCK BLK WIRE BLOWER FUSE BLOWER RELAY BLU WIRE CDM CHARGER 1 FUSE CHARGER 2 FUSE CHARGER LOCK RELAY CHARGER UNLOCK RELAY COOLING FAN FUSE COOLING FAN MOTOR E-SHIFTER 1 FUSE E-SHIFTER 2 FUSE E-SHIFTER RELAY ELECTRONIC ATM SHIFT DIAL ELECTRONIC WATER PUMP 1 (HV BATTERY) ELECTRONIC WATER PUMP 2 (HV BATTERY) EOP 1 FUSE EOP 2 FUSE EWP 1 FUSE EWP 2 FUSE FRONT ELECTRONIC OIL PUMP GRY WIRE ICCU LDC FUSE MDPS 1 FUSE MDPS UNIT MULTI FUSE 1 MULTI FUSE 2 NCA WIRE PNK WIRE POWER TAILGATE FUSE PTG UNIT REAR ELECTRONIC OIL PUMP REAR HEATED FUSE REAR HEATED RELAY RED WIRE RED/BLK WIRE RED/ORG WIRE SCU TO ICU JUNCTION BLOCK (DIAGRAM 6 OF 9) TO POWER OUTLET 1 FUSE (DIAGRAM 9 OF 9) TRAILER 1 FUSE TRAILER) VCMS VCU VCU 1 FUSE VESS FUSE VESS UNIT W/ POWER TAILGATE YEL WIRE

Go to component -> Power distribution circuit (1 of 9) -> CHARGER LOCK RELAY

Wiring diagram charger lock relay (3 of 4)

Wiring diagram charger lock relay for Kia EV6 I (2021-2024) (3 of 4)

Get access

AC V ACTUATOR GND ACTUATOR SIG B+ INPUT BLK WIRE BLU WIRE BRN WIRE CHARGER LOCK RELAY CHARGER UNLOCK RELAY CHARGING CONNECTOR (CP) CHARGING CONNECTOR (PD) CHARGING CONNECTOR LOCK/UNLOCK ACTUATOR CHARGING CONNECTOR TEMPERATURE SENSOR 2 (QUICK (-)) CHARGING CONNECTOR TEMPERATURE SENSOR 3 (NORMAL) CHARGING CONNECTOR TEMPERATURE SENSOR 3 (QUICK (+)) COMPUTER DATA LINES SYSTEM CORD SET ON/OFF G-CAN HI G-CAN LO GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES LCK RLY LCK RLY CTRL LCK/UNLCK ACTUATOR SIG ORG/ WIRE P/R JUNCTION BLOCK PNK WIRE RED WIRE RLY CTRL SOCKET PD TEMP SENS 1 (QUICK (+)) (+) TEMP SENS 1 (QUICK (+)) (-) WAKE-UP ICU TEMP SENS 2 (QUICK (-)) (+) TEMP SENS 2 (QUICK (-)) (-) LCK/UNLCK ACTUATOR GND TEMP SENS 3 (NORMAL) (-) UNLCK RLY UNLCK RLY CTRL VCMS (RIGHT SIDE OF LUGGAGE COMPT) WAKE-UP CHG WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Wiring diagram engine performance electric, long range (12 of 21) -> CHARGER LOCK RELAY
