Kia EV6 I (2021-2024) bmu txpl Wiring diagrams
This page contains all the electrical diagrams for the component. bmu txpl, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bmu txpl (1 of 2)
BATTERY MODULE 1
BATTERY MODULE 1 TEMPERATURE SENSOR
BATTERY MODULE 2
BATTERY MODULE 3
BATTERY MODULE 4
BATTERY MODULE 4 TEMPERATURE SENSOR
BATTERY SYSTEM ASSEMBLY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BMU OPD HI
BMU OPD LI
BMU RXNL
BMU RXPL
BMU TXNL
BMU TXPL
BRN WIRE
BUS BAR
CMU 1
GRN WIRE
GRY WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
SIG
TEMP SENS GND
TEMP SENS SIG
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance electric, long range (4 of 21) -> BMU TXPL
