Kia EV6 I (2021-2024) b+input on/start input pnk Wiring diagram
This page shows the only wiring diagram for the component.b+input on/start input pnk, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram b+input on/start input pnk (1 of 1)
12.3 INCH TFT
B+INPUT ON/START INPUT PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
BUCK-
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CONVERTER)
E-CAN
HIGH TRANCEIVER
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-F
INSTRUMENT CLUSTER
MCU
MDPS 1 FUSE
MDPS 2 FUSE
MDPS IND
MDPS UNIT
MULTI FUSE 1
P/R JUNCTION BLOCK
PCB BLOCK
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SIG 3 GND
WHT WIRE
Go to component -> Electronic power steering circuit -> B+INPUT ON/START INPUT PNK WIRE
