Kia EV6 I (2021-2024) air bag ind fuse Wiring diagram
This page shows the only wiring diagram for the component.air bag ind fuse, which is found in the car Kia EV6 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air bag ind fuse (1 of 1)
ADAS UNIT
ADAS UNIT (DRIVING)
ADP
AIR BAG 1 FUSE
AIR BAG IND FUSE
AMP
AVNT HEAD UNIT
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BUTTON TYPE
CLUSTER FUSE
CONNECTOR
CONSOLE FLOOR SWITCH
CONSOLE UPPER COVER SWITCH
CRASH PAD SWITCH
DATA LINK
DRIVER DOOR MODULE
DRIVER POWER SEAT MODULE
E-SHIFTER 3 FUSE
ELECTRO FLOOR SWITCH
ELECTROCHROMIC MIRROR
ELECTRONIC ATM SHIFT DIAL
FRONT AIR VENTILATION SEAT CONTROL MODULE
FRONT INVERTER
FRONT SEAT WARMER CONTROL MODULE
FRONT VIEW CAMERA (ADAS)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HEAD-UP DISPLAY
IBU
IBU 2 FUSE
ICU-A
ICU-B
ICU-C
ICU-F
ICU-G
INSTRUMENT CLUSTER
LEFT FRONT CORNER RADAR
LEFT REAR CORNER RADAR
MODULE 3 FUSE
MODULE 4 FUSE
MODULE 5 FUSE
MULTI- FUNCTION SWITCH
ORG/ WIRE
ORG/BLK WIRE
OVERHEAD CONSOLE
PASSENGER OCCUPANT DETECTION SENSOR
PASSENGER POWER SEAT MODULE
PNK WIRE
PNK/BLK WIRE
REAR INVERTER
REAR SEAT WARMER CONTROL MODULE
RED WIRE
RIGHT FRONT CORNER RADAR
RIGHT REAR CORNER RADAR
SMART CRUISE CONTROL RADAR
SRS CONTROL MODULE
STOP LAMP SWITCH
TO SMART PHONE WIRELESS CHARGER (DIAGRAM 9 OF 9)
TOUCH TYPE
VESS UNIT
W/ MEMORY
W/O VENTILATION
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (4 of 9) -> AIR BAG IND FUSE
