Kia EV6 I (2021-2024) a/c refrigerants solenoid valve Wiring diagrams
This page contains all the electrical diagrams for the component. a/c refrigerants solenoid valve, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c refrigerants solenoid valve (1 of 2)
Go to component -> Automatic a/c circuit (2 of 7) -> A/C REFRIGERANTS SOLENOID VALVE
Wiring diagram a/c refrigerants solenoid valve (2 of 2)
A/C BLOWER MOTOR
A/C COOLANT VALVE
A/C REFRIGERANTS SOLENOID VALVE
BLK WIRE
BLK/ORG WIRE
BSA CHILLER 1
FRONT POWER OUTLET
FRONT TRACTION MOTOR DISCONNECT ACTUATOR SHIELDS
HIGH MOUNTED STOPLAMP
HIGH PRESSURE VALVE
HV BATTERY ELECTRONIC WATER PUMP 1
IEB UNIT
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP
LEFT REAR POWER WINDOW SWITCH
NCA WIRE
ORG/BLK WIRE
POWER TAILGATE BUZZER
REAR CENTER LAMP
REAR INVERTER
REAR PE ELECTRONIC WATER PUMP
REAR POWER OUTLET
REFRIGERANTS VALVE 1
REFRIGERANTS VALVE 2
RIGHT HEADLAMP
RIGHT LICENSE LAMP
SBW ACTUATOR SHIELD
SUNROOF CONTROL UNIT
TAILGATE INNER SWITCH
TAILGATE LATCH
TAILGATE OUTER SWITCH
VCU
W/ POWER TAILGATE
W/ PRIVACY GLASS
W/O POWER TAILGATE
W/O PRIVACY GLASS
WASHER LEVEL SENSOR
WASHER MOTOR
Go to component -> Ground distribution circuit (3 of 7) -> A/C REFRIGERANTS SOLENOID VALVE
