Kia EV6 I (2021-2024) a/c coolant valve Wiring diagrams
This page contains all the electrical diagrams for the component. a/c coolant valve, in which he is found in the car Kia EV6 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c coolant valve (1 of 3)
A/C BLOWER MOTOR
A/C COOLANT VALVE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BSA CHILLER 1
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
ELECTRONIC WATER PUMP 1 (HV BATTERY)
ELECTRONIC WATER PUMP 2 (HV BATTERY)
FRONT HIGH VOLTAGE JUNCTION BLOCK
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HIGH PRESSURE VALVE
INTERLCOK -
ORG/ WIRE
PNK WIRE
POWER
REAR OF ENGINE COMPT)
RED WIRE
RED/BLK WIRE
REFRIGERANTS VALVE 1
REFRIGERANTS VALVE 2
SIG
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 7) -> A/C COOLANT VALVE
Wiring diagram a/c coolant valve (2 of 3)
A/C BLOWER MOTOR
A/C COOLANT VALVE
A/C REFRIGERANTS SOLENOID VALVE
BLK WIRE
BLK/ORG WIRE
BSA CHILLER 1
FRONT POWER OUTLET
FRONT TRACTION MOTOR DISCONNECT ACTUATOR SHIELDS
HIGH MOUNTED STOPLAMP
HIGH PRESSURE VALVE
HV BATTERY ELECTRONIC WATER PUMP 1
IEB UNIT
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP
LEFT REAR POWER WINDOW SWITCH
NCA WIRE
ORG/BLK WIRE
POWER TAILGATE BUZZER
REAR CENTER LAMP
REAR INVERTER
REAR PE ELECTRONIC WATER PUMP
REAR POWER OUTLET
REFRIGERANTS VALVE 1
REFRIGERANTS VALVE 2
RIGHT HEADLAMP
RIGHT LICENSE LAMP
SBW ACTUATOR SHIELD
SUNROOF CONTROL UNIT
TAILGATE INNER SWITCH
TAILGATE LATCH
TAILGATE OUTER SWITCH
VCU
W/ POWER TAILGATE
W/ PRIVACY GLASS
W/O POWER TAILGATE
W/O PRIVACY GLASS
WASHER LEVEL SENSOR
WASHER MOTOR
Go to component -> Ground distribution circuit (3 of 7) -> A/C COOLANT VALVE
Wiring diagram a/c coolant valve (3 of 3)
A/C 2 FUSE
A/C CONTROL MODULE
A/C COOLANT VALVE
ADAS UNIT
ADP
AIR BAG 2 FUSE
AVNT HEAD UNIT
BATTERY MANAGEMENT FUSE
BATTERY SYSTEM ASSEMBLY
BLK WIRE
BLOWER RELAY
BMU+
BRAKE SWITCH FUSE
BRN WIRE
BSA CHILLER 1
CONSOLE FLOOR SWITCH
CONSOLE MOOD LAMP (LOWER)
CONSOLE MOOD LAMP (UPPER)
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR MOOD LAMP
DRIVER DOOR OUTSIDE HANDLE
E-CALL FUSE
ECS FUSE
FROM B+4 FUSE (DIAGRAM 2 OF 9)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HEAD-UP DISPLAY
HIGH PRESSURE VALVE
IAU FUSE
IBU
IBU 1 FUSE
ICU-A
ICU-C
ICU-F
INSTRUMENT CLUSTER
IPS CONTROL MODULE
LEFT CRASH PAD MOOD LAMP
LEFT REAR DOOR MOOD LAMP
LONG TERM LOAD LATCH RELAY
MEMORY 1 FUSE
MEMORY 2 FUSE
MOOD LAMP UNIT
MULTIMEDIA FUSE
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MOOD LAMP
PASSENGER DOOR OUTSIDE HANDLE
PNK WIRE
RED WIRE
RED/BLK WIRE
REFRIGERANT VALVE 1
REFRIGERANT VALVE 2
RIGHT CRASH PAD MOOD LAMP
RIGHT REAR DOOR MOOD LAMP
SPARE 3 (B+) FUSE
SRS CONTROL MODULE
STOP LAMP SWITCH
TO MODULE 1 FUSE (DIAGRAM 9 OF 9)
TWO TURN UNLOCK RELAY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (8 of 9) -> A/C COOLANT VALVE
