Kia Cerato IV facelift (2021-2024) wiper sw sig Wiring diagram
This page shows the only wiring diagram for the component.wiper sw sig, which is found in the car Kia Cerato IV facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper sw sig (1 of 1)
2.0L
BLK WIRE
BRN WIRE
E/R-C
E/R-D
FRONT WASHER MOTOR SW POWER
FRONT WASHER SWITCH
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER LOW BACKUP SIG
FRONT WIPER MOTOR
GND (BCM)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
ICU JUNCTION BLOCK
ICU-E
INT/VOL SW SIG
MIST
MULTI- FUNCTION SWITCH
ON INPUT
ORG/ WIRE
PARKING SWITCH
PCB BLOCK
RED WIRE
VOL 1 (FAST)
VOL 2
VOL 3
VOL 4
VOL 5 (SLOW)
WASHER FUSE
WHT WIRE
WIPER FUSE
WIPER LOW SWITCH
WIPER RELAY
WIPER SW SIG
YEL WIRE
Go to component -> Wiper/washer circuit (2 of 2) -> WIPER SW SIG
