Kia Cerato IV facelift (2021-2024) pocket lamp Wiring diagram
This page shows the only wiring diagram for the component.pocket lamp, which is found in the car Kia Cerato IV facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pocket lamp (1 of 1)
B-CAN
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DOOR OPEN IND
DRIVER SMART KEY OUTSIDE HANDLE
GRN WIRE
GROUND
HOT IN ON OR START
HOT WITH LONG TERM LOAD LATCH RELAY ENERGIZED
IBU (RIGHT END OF DASH)
ICU JUNCTION BLOCK
ICU-E
ICU-F
INSTRUMENT CLUSTER
LAMP
M-CAN
MEM PWR
MEMORY 1 FUSE
MICOM
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MOOD LAMP
PASSENGER SMART KEY OUTSIDE HANDLE
PNK/BLK WIRE
POCKET
POCKET LAMP
RED WIRE
REG
SEG LCD (3.5 INCH)
TFT LCD
TFT LCD (4.2 INCH)
TFT LCD DRIVE
TRANSCEIVER/
TRUNK OPEN IND
WHT WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> POCKET LAMP
