Kia Cerato IV facelift (2021-2024) navigation, sound systems Wiring diagram
This page shows the only wiring diagram for the component.navigation, sound systems, which is found in the car Kia Cerato IV facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation, sound systems (1 of 1)
AUDIO (W/O NAVIGATION) A/V, NAVIGATION HEAD UNIT (W/ NAVIGATION)
BACKUP SIGNAL
BLK WIRE
BLU WIRE
BRN WIRE
ELECTROCHROMIC MIRROR
GRN WIRE
GROUND
HOT IN ON OR START
ICU JUNCTION BLOCK
ICU-F
ILL
IND SW SNSR
KEYPAD
KEYPAD GND
KEYPAD SIGNAL
MODULE 5 FUSE
MTS KEY PAD SIGNAL
NAVIGATION, SOUND SYSTEMS
ON/START INPUT
ORG/ WIRE
PCB
PHONE
RED WIRE
REMOTE CTRL SW GND
SOS
UVO
W/O NAVIGATION W/ NAVIGATION
Go to component -> Electrochromic mirror circuit -> NAVIGATION, SOUND SYSTEMS
