Kia Cerato IV facelift (2021-2024) driver side impact pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.driver side impact pressure sensor, which is found in the car Kia Cerato IV facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side impact pressure sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER CURTAIN AIR BAG
DRIVER SEAT ANCHOR PRETENSIONER
DRIVER SEAT BELT PRETENSIONER (ADAPTIVE LOAD LIMITER)
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT PRESSURE SENSOR
DRIVER SIDE IMPACT SENSOR
DRV CURTAIN AIR BAG HIGH
DRV CURTAIN AIR BAG LOW
DRV SEAT ANCHOR PRETENSIONER HIGH
DRV SEAT ANCHOR PRETENSIONER LOW
DRV SEAT BELT PRETENSIONER HIGH
DRV SEAT BELT PRETENSIONER LOW
DRV SIDE AIR BAG HIGH
DRV SIDE AIR BAG LOW
DRV SIDE IMPACT SENS HIGH
DRV SIDE IMPACT SENS LOW
DRV SIDE IMPACT SENS PRESSURE HIGH
DRV SIDE IMPACT SENS PRESSURE LOW
GRN WIRE
GRY WIRE
ORG/ WIRE
PASS CURTAIN AIR BAG HIGH
PASS CURTAIN AIR BAG LOW
PASS SEAT BELT PRETENSIONER HIGH
PASS SEAT BELT PRETENSIONER LOW
PASS SIDE AIR BAG HIGH
PASS SIDE AIR BAG LOW
PASS SIDE IMPACT PRESSURE SENS HIGH
PASS SIDE IMPACT PRESSURE SENS LOW
PASS SIDE IMPACT SENS HIGH
PASS SIDE IMPACT SENS LOW
PASSENGER CURTAIN AIR BAG
PASSENGER SEAT BELT PRETENSIONER (ADAPTIVE LOAD LIMITER)
PASSENGER SIDE AIR BAG
PASSENGER SIDE IMPACT PRESSURE SENSOR
PASSENGER SIDE IMPACT SENSOR
RED WIRE
SRS CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> DRIVER SIDE IMPACT PRESSURE SENSOR
