Kia Cerato IV facelift (2021-2024) driver power window motor Wiring diagram
This page shows the only wiring diagram for the component.driver power window motor, which is found in the car Kia Cerato IV facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver power window motor (1 of 1)
AUTO DOWN
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CONTROL UNIT)
DOOR LOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
DRIVER POWER WINDOW MOTOR
DRIVER WINDOW SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ILL
IPS CONTROL MODULE
LEFT POWER WINDOW RELAY
LEFT REAR WINDOW SWITCH
OFF
ORG/ WIRE
P/WINDOW LH FUSE
P/WINDOW RH FUSE
PASSENGER WINDOW SWITCH
PNK WIRE
POWER WINDOW MAIN SWITCH
PWR WINDOW RELAY CONTROL
RED WIRE
RIGHT POWER WINDOW RELAY
RIGHT REAR WINDOW SWITCH
WHT WIRE
WINDOW LOCK SWITCH
YEL WIRE
Go to component -> Power windows circuit, w/ driver auto down power window (1 of 2) -> DRIVER POWER WINDOW MOTOR
