Kia Cerato IV (2018-2022) smart key bumper antenna Wiring diagram
This page shows the only wiring diagram for the component.smart key bumper antenna, which is found in the car Kia Cerato IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram smart key bumper antenna (1 of 1)
1.6L
2.0L
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CENTER REAR OF LUGGAGE COMPT)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
IGNITION LOCK SWITCH
IGNITION LOCK, CLUTCH SWITCH
ILL
IVT DCT
IVT/DCT
M/T
ORG/ WIRE
P POSITION SWITCH
PNK/BLK WIRE
PWR
RED WIRE
RHEOSTAT
SMART KEY ANTENNA (INTERIOR 1)
SMART KEY ANTENNA (INTERIOR 2)
SMART KEY BUMPER ANTENNA
SMART KEY TRUNK ANTENNA
SPORT MODE SWITCH
SSB SW 1
SSB SW 2
SSB SYMBOL
START/STOP BUTTON SWITCH
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, w/ smart key system (2 of 3) -> SMART KEY BUMPER ANTENNA
