Kia Cerato IV (2018-2022) sensor sply Wiring diagram
This page shows the only wiring diagram for the component.sensor sply, which is found in the car Kia Cerato IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sensor sply (1 of 1)
APS 1 SPLY
APS 2 SIG
APT SIG
BATTERY SENS (LIN)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
BVS SPLY
CCP-CAN HIGH
CCP-CAN LOW
CCV CTRL
COMPUTER DATA
E/R-A
E/R-B
E/R-D
ECU 1 FUSE
ECU 2 FUSE
ENG CTRL RLY CTRL
ENGINE CONTROL RELAY
ENGINE RPM SIG
FTP SENS SIG
FUEL PUMP RLY CTRL
FUEL TANK LVL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
IGN COIL FUSE
IMMO COMM LINE
KNOCK SENS GND
KNOCK SENS SIG
KNOCK SENSOR
LINES SYSTEM
MAP SENS (IAT SIG)
MAP SENS SIG
NCA WIRE
ORG/ WIRE
OXYGEN SENSOR (UP)
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PCSV CTRL
PNK WIRE
PURGE CONTROL SOLENOID VALVE
RCV CTRL
RED WIRE
RPS SIG
SENSOR 1 FUSE
SENSOR 2 FUSE
SENSOR 3 FUSE
SENSOR SPLY
TPS 2 SIG
TPS GND
TPS SPLY
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo (4 of 6) -> SENSOR SPLY
