Kia Cerato IV (2018-2022) parking distance warning buzzer control Wiring diagram
This page shows the only wiring diagram for the component.parking distance warning buzzer control, which is found in the car Kia Cerato IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking distance warning buzzer control (1 of 1)
AMP
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
GRN WIRE
HOT IN ON OR START
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
IBU
ICU JUNCTION BLOCK
ICU-E
ICU-F
INSTRUMENT CLUSTER
LEFT REVERSE PARKING DISTANCE WARNING SENSOR
LEFT REVERSE PARKING DISTANCE WARNING SENSOR (CENTER)
LIN
M-CAN TRANSCEIVER
MEMORY 1 FUSE
MICOM
MODULE 4 FUSE
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PARKING DISTANCE WARNING BUZZER
PARKING DISTANCE WARNING BUZZER CONTROL
PARKING DISTANCE WARNING REVERSE-POWER
PARKING DISTANCE WARNING SENSOR PWR
PNK/BLK WIRE
RED WIRE
REG
RIGHT END OF DASH)
RIGHT REVERSE PARKING DISTANCE WARNING SENSOR
RIGHT REVERSE PARKING DISTANCE WARNING SENSOR (CENTER)
SPEAKER
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Parking assistant circuit -> PARKING DISTANCE WARNING BUZZER CONTROL
